Ventis HE275CF High-Efficiency Stove Bundle

Ventis HE275CF High-Efficiency Stove Bundle

SKU VB00017-AC01375K
by Ventis
$0
$5,139.00 - $5,339.00
$5,139.00
$5,139.00 - $5,339.00
$5,139.00
Availability:
in stock
Availability:
in stock

The Ventis HE275CF High-Efficiency Stove Bundle is a powerful heating solution designed for spaces ranging from 750 to 2,200 square feet. This stove features a large, contemporary design with a single door and is EPA 2020 certified, ensuring it meets the latest environmental standards. Utilizing non-catalytic combustion technology, it efficiently heats your space while maintaining clean air quality. The bundle includes essential components like a 6" Ventis stainless steel anchor plate, a fresh air intake adapter, and molded refractory stones for enhanced durability. Additionally, installation is authorized on the Island of Montreal, making it a versatile choice for various locations.

Order Processing and Shipping

Rise ships manufacturer direct. We work hard so you receive your product(s) as quickly as possible. Learn more about our order processing & shipping times here.
 More payment options

Specifications

Optimum efficiency70%
Average particulate emission rate1.2 g/h
EPA loading volume1.94 ft³
Maximum heat output (dry cordwood)80,000 BTU/h
Maximum overall heat output rate60,700 BTU/h (17.79 kW)
Minimum overall heat output rate12,700 BTU/h (3.72 kW)
Average overall efficiency (dry cordwood, HHV)64.00%
Baffle typeHigh density insulation board
Recommended chimney diameter6"
Flue outlet diameter6"
Firebox size (Height)12 1/8"
Firebox size (Width)20 3/4"
Firebox size (Depth)12 7/8"
Overall dimension (Height)40 5/8"
Overall dimension (Width)36 3/4"
Overall dimension (Depth)27 1/4"
Door opening size (Height)10 1/2"
Door opening size (Width)25 3/8"
High-efficiency certified applianceYes, EPA 2020 approved
WarrantyLifetime limited
Minimum chimney height15"
Maximum log length20"
Average overall efficiency (dry cordwood, LHV)68%
Optimum heat transfer efficiency68%
Recommended heating area750 - 2,200 ft²
Average CO98 g/h
Maximum burn time8 h
Fuel typeDry cordwood (16" recommended)
Overall firebox volume2.5 ft³
Canadian Standard (emissions)CSA B415.1-10
USA Standard (emissions)EPA
Canadian Standard (safety)ULC S610
USA Standard (safety)UL 127
Moulded refractory panelsYes
Shipping weight495 lb (225 kg)
Log positioningLoading over width
Glass surface (W x H)24" x 10 5/8"
Stainless-steel secondary-air systemYes
Combustion technologyNon-catalytic
Certified according to applicable standardsCAN/USA accredited laboratory
Type of chimneyCAN/ULC S629, UL 103 HT (2100 °F)
Door typeSingle, glass with cast iron frame
Premium quality blower included (CFM)Optional
Glass typeCeramic glass





ClearancesCanadaUnited States
Base of the unit to ceiling**76"76"
Combustible side mantle to unit8"8"
Combustible top mantle to unitN.A.N.A.
Combustible side wall to unit13"13"
Base of the unit to a combustible shelf48"48"

Documentation

Installation and User Manual
Appliance Dimensions
