MRCOOL DIY Easy Pro Ductless Mini-Split Heat Pump System

SKU EZPRO-09-HP-11516
by MRCOOL
Sold out
Original price $1,252.00 - Original price $1,698.00
Original price
$1,252.00
$1,252.00 - $1,698.00
Current price $1,252.00
Availability:
Out of stock
Availability:
Out of stock
Availability:
Out of stock
Availability:
Out of stock

The easy-to-install MRCOOL Easy Pro® Ductless Mini-Split Heat Pump System can heat or cool a space of up to 350 square feet with a 20 SEER rating.

It includes a 16-foot pre-charged line set with Fast Connection® fittings. This system has many features, such as the Follow Me® feature that keeps you comfortable no matter where you are in the room, along with convenient operational modes such as Sleep mode, Auto mode, or Timer mode. Maintaining the system is easy as the air filters only need to be rinsed, dried, and replaced, while the indoor and outdoor units only need to be cleaned with a damp or dry cloth. You can control this system with the included remote, the SmartHVAC app, or your Amazon Alexa or Google Assistant.

Enjoy protected comfort thanks to the 1-year compressor warranty and 2-year parts warranty. This energy-efficient, feature-packed HVAC system can be easily installed and easily maintained while providing the ultimate comfort.

Features:

  • Gold Fin® condenser: corrosion resistant
  • Energy-Efficient DC Inverter
  • Low ambient cooling: cooling down to 5F exterior temperatures, the ideal system for computer server rooms, greenhouses, and any other applications that require cooling all year
  • Includes features such as timer mode, refrigerant leakage detection, and more
  • Systems include our SmartHVAC WiFi Control Module with improved setup and enhanced functionality for Apple and Android smart devices. Works with Amazon Alexa. Works with Google Assistant.
  • Quiet Running

    Order Processing and Shipping

    Rise ships manufacturer direct. We work hard so you receive your product(s) as quickly as possible. Learn more about our order processing & shipping times here.

    Carbon-neutral shipping with Shopify Planet
    Carbon-neutral shipping on all orders
    6,911kg
    shipping emissions removed
    That's like...
    17,691
    miles driven by an average gasoline-powered car
    We fund innovations in...
    Direct Air Capture
    Bio Oil
    Mineralization

    Model Comparison

    MODELEZPRO-09-HP-11516EZPRO-12-HP-11516EZPRO-18-HP-23016EZPRO-24-HP-23016
    GTIN810035935198810035935204810035935211810035935228
    UPC810035935198810035935204810035935211810035935228
    UNIT TYPEMini-Split
    SHORT DESCRIPTIONMRCOOL® DIY Easy Pro® 9k BTU Ductless Mini-Split Heat Pump SystemMRCOOL® DIY Easy Pro® 12k BTU Ductless Mini-Split Heat Pump SystemMRCOOL® DIY Easy Pro® 18k BTU Ductless Mini-Split Heat Pump SystemMRCOOL® DIY Easy Pro® 24k BTU Ductless Mini-Split Heat Pump System
    SEER201818.518
    SEER22018.919.318
    EER11.599.89
    EER211.599.89
    COP 473.142.953.13.08
    HSPFHSPF4/HSPF5 : 10.3/8.5HSPF4/HSPF5 : 11.1/9.5HSPF4/HSPF5 : 9.7/8HSPF4/HSPF5 : 10.3/8.4
    HSPF2HSPF2-4/HSPF2-5 : 9.4/7.2HSPF2-4/HSPF2-5 : 9/18.9HSPF2-4/HSPF2-5 : 8.6/6.7HSPF2-4/HSPF2-5 : 8.3/6.5
    CFM238.82/170.00/137.06300.00/241.18/176.47382.35/300.00/264.71549.41/404.12/333.53
    COOLING CAPACITY9000 BTU12000 BTU17000 BTU24000 BTU
    HEATING CAPACITY10000 BTU12000 BTU18000 BTU25000 BTU
    VOLTAGE115 V115 V208-230 V208-230 V
    PHASE1111
    CYCLE60 Hz60 Hz60 Hz60 Hz
    MAX FUSE BREAKER30 A30 A25 A35 A
    MIN CIRCUIT AMPACITY20 A20 A15.5 A21 A
    RATED LOAD14.5 A13.9 A10 A15 A
    ZONE CAPACITY1111
    REFRIGERANT TYPER-410AR-410AR-410AR-410A
    REFRIGERANT VOLUME27.87 oz32.10 oz49.03 oz65.96 oz
    DECIBEL RATING34 dBA35.5 dBA39 dBA40 dBA
    DECIBEL RATING LOW22.5 dBA27 dBA23.5 dBA27 dBA
    DECIBEL RATING HIGH38.5 dBA42 dBA44.5 dBA45 dBA
    MIN AMBIENT COOL5F - 122F5F - 122F5F - 122F5F - 122F
    MIN AMBIENT HEAT5F - 75.2F5F - 75.2F5F - 75.2F5F - 75.2F
    MAX LINESET LENGTH82ft82ft98ft164ft
    LIQUID LINE SIZE1/4in1/4in1/4in3/8in
    SUCTION LINE SIZE1/2in1/2in1/2in5/8in
    COMPRESSOR MOTOR TYPERotaryRotaryRotaryTwin - Rotary
    CONDENSER FAN MOTOR RPM850/500850/5001200/700810/720
    BLOWER MOTOR SPEEDS3333
    BLOWER MOTOR RPM1050/810/6901200/1040/9601200/1000/9001100/940/860
    FILTER TYPEWashableWashableWashableWashable
    FAN ONLY OPTIONYesYesYesYes
    SLEEP MODEYesYesYesYes
    AUTO COOLYesYesYesYes
    WIFI COMPATIBILITYyesyesyesyes
    APP COMPATIBILITYyesyesyesyes
    WORKS WITH IOSYesYesYesYes
    WORKS WITH ANDROIDYesYesYesYes
    REMOTE CONTROL INCLUDEDYesYesYesYes
    ENERGY STAR CERTIFIEDyesyesyesyes
    AHRI CERTIFIEDyesyesyesyes
    REGISTERED WARRANTY2-year Parts/1-year Compressor2-year Parts/1-year Compressor2-year Parts/1-year Compressor2-year Parts/1-year Compressor
    REGISTERED PARTS WARRANTY2 years2 years2 years2 years
    REGISTERED COMPRESSOR WARRANTY1 year1 year1 year1 year
    PROPOSITION 65 WARNINGYesYesYesYes
    CONDENSER DEPTH10.63 in10.63 in11.93 in13.46 in
    CONDENSER HEIGHT19.49 in19.49 in21.85 in26.5 in
    CONDENSER WIDTH28.35 in28.35 in30.12 in35.04 in
    CONDENSER WEIGHT54.45 lbs55.11 lbs63.49 lbs97.66 lbs
    AIR HANDLER DEPTH7.87 in7.87 in8.98 in9.21 in
    AIR HANDLER HEIGHT11.5 in11.61 in12.64 in13.27 in
    AIR HANDLER WIDTH28.70 in31.57 in38.23 in42.60 in
    AIR HANDLER WEIGHT17.64 lbs24.03 lbs29.98 lbs35.27 lbs
