by Jackery

Jackery SolarSaga 500 X - 21-0002-000093

SKU 21-0002-000093

Sold out

$999.00 - $999.00

$999.00

$999.00 - $999.00

$999.00

Availability:

Out of stock

Jackery SolarSaga 500 X - 21-0002-000093 is a high-performance 500W solar panel engineered for exceptional efficiency and outdoor durability. Designed with advanced TOPCON cell technology, it delivers a 25% conversion rate and dual-sided solar absorption, maximizing energy capture in any outdoor environment. Whether you're powering a Jackery 5000 Plus or setting up a DIY solar station, this foldable, portable system ensures plug-and-play convenience. Its rugged build, including IP68 waterproofing and a wide temperature range of -40℃ to 85℃, guarantees long-term reliability in diverse climates. Compatible with multiple Jackery Explorer models, it’s the ideal solution for outdoor enthusiasts and sustainable homeowners alike.

Features:

500W high-efficiency solar output with 25% conversion using TOPCON cells
Dual-sided solar panel design captures more sunlight
Foldable and portable design for easy transport and setup
IP68 waterproof rating and durable build for extreme weather conditions
Plug-and-play DIY assembly with secure mounting options
Operates from -40℃ to 85℃ for all-season use
Compatible with Explorer 5000 Plus, 3000 Pro, 2000 Plus, 1000 Plus, and 1000 V2
5-year manufacturer warranty for peace of mind
Includes six individual SolarSaga 85 panels, usable separately

Specifications

Specification	Details
Product Configuration	Six SolarSaga 85 panels (can be used individually)
Peak Power (STC)	500W ± 5%
Peak Power (BNPI)	545W ± 5%
Open Circuit Voltage (VOC - STC)	48.5V ± 5%
Open Circuit Voltage (VOC - BNPI)	49.2V ± 5%
Short Circuit Current (Isc - STC)	13.02A ± 5%
Short Circuit Current (Isc - BNPI)	13.86A ± 5%
Power Voltage (Vmp - STC)	41.7V ± 5%
Power Voltage (Vmp - BNPI)	42.5V ± 5%
Power Current (Imp - STC)	12.0A ± 5%
Power Current (Imp - BNPI)	12.84A ± 5%
Maximum System Voltage	600V DC
Maximum Reverse Current	15A
Bifaciality Coefficient (Back/Front)	Pmax > 80%, Voc > 97%, Isc > 80%
Voltage Temperature Coefficient	-0.26% / ℃
Power Temperature Coefficient	-0.32% / ℃
Operating Temperature Range	-40°F to 185°F (-40°C to 85°C)
Waterproof Rating	IP68
Protection Class Against Electric Shock	Class II
Weight	22.05 lbs ± 2.20 lbs (10.5 kg ± 0.5 kg)
Folded Dimensions	39.21 × 20.71 × 3.82 in (996 × 526 × 97 mm)
Unfolded Dimensions	98.15 × 39.21 × 11.57 in (2493 × 996 × 294 mm)
Compatible With	Explorer 5000 Plus, 3000 Pro, 2000 Plus, 1000 Plus, 1000 V2
DIY Setup Note	Do not connect more than six 85W panels to a single DC8020 port
Warranty	5 Years
