Vents Frigate Energy Recovery Ventilator

SKU ERV-80
Original price $930.00 - Original price $1,557.00
Original price
$930.00
$930.00 - $1,557.00
Current price $930.00
Availability:
in stock, ready to be shipped
Availability:
in stock, ready to be shipped
Availability:
in stock, ready to be shipped
Availability:
in stock, ready to be shipped
Availability:
in stock, ready to be shipped
Availability:
in stock, ready to be shipped
Availability:
in stock, ready to be shipped
Availability:
in stock, ready to be shipped

Experience the ultimate indoor air quality with the Vents-US Frigate Energy Recovery Ventilator. This comprehensive ventilation system series is meticulously engineered to ensure a continuous influx of fresh air while effectively expelling an equivalent amount of stale air, creating a healthier living environment. Versatile and adaptable, it is perfect for various settings, including bathrooms, kitchens, apartments, cottages, and small offices. Equipped with easily washable MERV 6 air filters in both exhaust and supply air streams, the ventilator guarantees clean and purified air circulation. Its steel casing is fortified with a high-quality multilayer aluminum and zinc alloy, providing exceptional corrosion resistance for enhanced durability. The ventilator's automatic recovery core frost protection feature ensures worry-free operation during colder climates. With a cross-flow heat recovery core utilizing an enthalpy membrane, this system maximizes energy efficiency by efficiently transferring heat between incoming and outgoing air streams.

    LEARN MORE WITH AI

    Have a question about this product?

    chat-bubble
    Send message
    Was this helpful?
    Yes
    No
    Thanks for the feedback!

    Comparison Chart

    ModelERV 80ERV 80 ECERV 80RERV 120ERV 120 ECERV 120R ECERV 150ERV 150 EC
    Supply voltage (V)60 Hz
    Rated input power [W]746161156198198192186
    Maximum current [A]0.60.90.91.32.52.51.62.5
    Air capacity [cfm @ 0.4 in. w.g.]536161114150133150162
    Transported air temperature [F (°C)]-13(-25) up to +122(+55)
    Insulation thickness [inch (mm)Polystyrene 1” (25)
    Extract filter: material/filtration classPoret PPI 20/MERV6
    Supply filter: material/filtration classPoret PPI 20/MERV6
    Connected air duct diameter [inch (mm)]Ø 5” (125)
    RecirculationAutomatic recirculation damper (R option) for effective cold protection
    FilterWashable MERV 6 air filters in exhaust and supply air streams
    Defrost SystemDefrost system is activated when the outdoor temperature falls below
    DrainageNo drain needed on ERV models
    Weight lbs29.829.835.3444457.346.353
    Weight kg13.513.5162020262124.4
    Heat recovery core typeCross-flow
    Heat recovery core materialEnthalpy Membrane
